- This 1/10-scale RTR (Ready-to-Run) off-road truck features a powerful remote control system and 3S brushless electronics. Its lightweight construction utilizes race-track-proven materials, enabling exhilarating performance across diverse terrains and conditions
- SBK10 Buggy effortlessly handles dirt, asphalt, and grass surfaces, with its adjustable aluminum hydraulic shock absorbers effectively absorbing road bumps. Mounted on aluminum alloy shock towers, the shocks feature shock caps and protective covers to ensure exceptionally smooth damping performance
- SBK10 features high-grip multi-purpose tires, while its low-drag rear wing enhances vehicle stability. These two design elements work in tandem to ensure confident handling and responsive performance at high speeds
- Front and rear differentials ensure consistent rotational speeds during turns and curved driving, while front and rear anti-roll bars enhance vehicle stability and prevent rollovers. These two designs collectively deliver superior handling during cornering, effortlessly outperforming competitors
Model: SBK10(Storm Breaker）
Proportion: 1/10
Product Versions: Carbon Fiber/Metal Versions
Body:
Carbon Fiber RTR Version —12.MM PC
Standard RTR Version —1.2MM PVC
Battery Compartment: 110x36x30mm
Speed: 50-80km/H
Wheelbase: 275mm
Length: 400mm
Width: 250mm
Height: 133mm
Front Tires:Ø83×32mm
Rear Tires:Ø83×39mm
Driving Mode: 4WD (All-Wheel Drive)
Transmission Mode: Central Differential
ESC:
Carbon Fiber RTR Version —60A Independent Brushless ESC with Cooling Fan
Standard RTR Version —45A Independent Brushless ESC with Cooling Fan
Motor :
Carbon Fiber RTR Version —3650-2650KV Brushless Motor
Standard RTR Version —2852-3100KV Brushless Motor
Battery :3s 2200mah 35c Li-Polymer
Steering Gear :
Carbon Fiber RTR Version —20kg Standard Servo with Brushed Motor（Digital servo）
Standard RTR Version —11kg Fully Waterproof Metal Gear Steering Gear
Remote Control :2.4GHZ 6-Channel Tyrannosaurus Remote Control (Remote Control Distance Is About 350).
Support Voltage: 6V
Shock Tower: 4mm 7075 Aluminum Alloy, CNC
Chassis: 2.5mm 6061 Aluminum Alloy, Oxidized Sand Blasting, Black Anode.
Shock Absorber: All-Metal Hydraulic Shock Absorber
Motor Mount:
Carbon Fiber RTR Version —Aluminum Alloy, Supports 36-Series Motor, with Adjustable Slider
Standard RTR Version —Aluminum Alloy, Supports 28-Series Motor, with Adjustable Slider
Bearing System:Full Metal Ball Bearing Throughout
1. Instruction Manual*1
2. Brand Decals*2
3. Body Decal Set*1
4. Rear Wing Decal Set*1
5. L-shaped Hex Wrench 1.5mm*1
6. L-shaped Hex Wrench 2.0mm*1
7. L-shaped Hex Wrench 2.5mm*1
8. Phillips Socket*1
9. Motor Gear*1 + Machine Screw*1 (Carbon Fiber Version: 27T / Metal Version: 19T)
10. Differential Sealing Gasket*2
11. ESC Double-Sided Tape*1 + Switch Double-Sided Tape*1
12. Cable Ties*2 (Black)
13. Battery charging cable*1
14. Tail wing mounting screws and washers*2
15. Voltage feedback wire*1
16. Large battery box*1
17. Tail wing*1
18. White tire paint pen*1
19. Modified front bumper*1
20. Battery zip ties*2
